    Getting started

    This guide explains how to integrate external systems with SX Digital Pay to generate single-use payment links and track their lifecycle through API calls and webhooks. The external system creates a link, redirects the customer, and checks the link details (or webhook) to know whether a payment was completed.

    Environments#

    Production: https://app.sxdigitalpay.com/api/v1; Requires API key provided in Integration menu on Merchant's Dashboard.
    Sandbox: https://sandbox.sxdigitalpay.com/api/v1; Requires the shared sandbox API key provided in Authentication.
    Sandbox limitations:
    GET /payment-links is disabled in sandbox and returns 403.
    You can create payment links in Create single-use payment link and open the quote page (fields paymentLink.url or paymentLink.shortUrl on response) to simulate payments.
    Webhooks are not dispatched automatically in sandbox; use the Sandbox panel on the quote page to simulate events and review responses.

    Authentication#

    Send either header x-api-key: <api-key> or Authorization: Bearer <api-key>. See Authentication for full details.

    Rate limiting#

    60 requests per minute per API key.
    Responses include X-RateLimit-Limit, X-RateLimit-Remaining, X-RateLimit-Reset and return 429 + Retry-After when the limit is exceeded.

    Core Flow#

    1.
    Create a payment link
    POST /payment-links
    Required fields: title, amount (> 25).
    Optional but recommended: externalReference (idempotency per merchant), expiresAt, metadata (JSON object), webhookUrl, webhookSecret (otherwise generated and returned only once), callbackUrl (redirect after successful payment).
    2.
    Redirect the customer to the link
    Use url or shortUrl from the response. The checkout and payment capture happen on SX Digital Pay.
    If you set callbackUrl, the checkout automatically redirects the customer to that URL after the payment is completed.
    3.
    Track the link and payments
    Read paymentStatus (NOT_STARTED, PENDING, COMPLETED) and payments[] from GET /payment-links/{id}.
    Or subscribe to the webhook payment_link.payment_status_changed to be notified when the link's paymentStatus changes.
    Sandbox note: you can create links and open the quote page (fields paymentLink.url or paymentLink.shortUrl on Create single-use payment link response). Use the Sandbox panel to simulate link status and payment status changes.

    Key Endpoints#

    Create link: POST /payment-links
    List links: GET /payment-links (filters: status, externalReference, pagination) Production only
    Get link details (payments + paymentStatus): GET /payment-links/{id}
    Payments are embedded in the link details response; there is no separate payments endpoint.

    Link Status and Behavior#

    ACTIVE: link is usable; isActive is true while not expired.
    INACTIVE: disabled by the platform or business logic.
    EXPIRED: past expiresAt or otherwise expired.
    Links are single-use (isMultiUse always false). After a payment is completed, expect the link to become inactive and receive a webhook if configured.
    paymentStatus (aggregated by link):
    NOT_STARTED: no payments exist for the link.
    PENDING: at least one payment exists but none completed.
    COMPLETED: the payment has been completed; the payment balance has already been added to the merchant's account.

    Webhooks#

    Configure webhookUrl when creating the link to receive events:
    payment_link.created
    payment_link.status_changed
    payment_link.payment_status_changed
    payment_link.payment_status_changed is the simplest way to know when a link starts receiving payments (NOT_STARTED -> PENDING) and when a payment is completed (PENDING -> COMPLETED). The payload also includes the latest payment summary and counts.
    Headers:
    x-sxpay-signature: HMAC-SHA256 of "{timestamp}.{rawBody}" using the link's webhookSecret.
    x-sxpay-timestamp: Epoch milliseconds.
    Verify the signature before processing. If verification fails, reject the webhook.

    Automatic Retries#

    SX Digital Pay automatically retries failed webhook deliveries with exponential backoff (1min, 5min, 15min, 1h, 4h, 12h). Return a 2xx status to acknowledge successful receipt. For complete details, see Webhook Delivery System.
    Sandbox note: use the Sandbox panel on the quote page to simulate webhook events and inspect the webhook responses. Logs are stored in the browser (localStorage) for your session.

    Typical Integration Steps (Example)#

    1.
    Create link:
    2.
    Redirect customer to the returned url (or shortUrl).
    3.
    Receive webhook payment_link.payment_status_changed with paymentStatus: COMPLETED (and latestPayment) or poll GET /payment-links/{id} to reconcile.
    4.
    When you receive a completed payment, mark the order as paid in your system.

    Polling vs. Webhooks#

    Prefer webhooks for near real-time updates.
    Use polling as a backup (e.g., on webhook failures or for periodic reconciliation) against GET /payment-links/{id} to read paymentStatus and payments[].

    Errors and Responses#

    401 Missing/invalid API key.
    403 Merchant inactive or sandbox-only restriction (e.g., list endpoint or payment continuation in sandbox).
    404 Resource not found (link or payment).
    400 Validation issues (title, amount, dates, webhookUrl).
    409 externalReference already exists for the merchant.

    Data Models (high level)#

    PaymentLink: id, title, amount, currency, status, paymentStatus, isMultiUse:false, isActive, isExpired, expiresAt, url, shortUrl, metadata, optional callbackUrl, optional webhookUrl, optional webhookSecret (only at creation).
    Payments embedded in link details: paymentsSummary (counts by status) plus payments[] with id, status, timestamps, optional customer, optional quote (amount, currency, paymentMethod, installments, totalBRL).
    Payment status (per payment): PENDING | COMPLETED | DISPUTED | REFUNDED.

    Recommendations#

    Use externalReference for idempotency and reconciliation on your side.
    Store the webhookSecret securely; it is only returned at creation time.
    Validate HMAC signatures and check x-sxpay-timestamp freshness to prevent replay attacks.
    Implement idempotency on your webhook endpoint using the event id field, as SX Digital Pay may deliver the same event multiple times during retries.
    Return 2xx responses quickly (< 20 seconds) to acknowledge receipt; process payloads asynchronously if needed.

    Support#

    If you have any questions, concerns, or wish to report a bug, please do not hesitate to contact us: developers@sxdigitalpay.com.
